MakerBot Method X Carbon Fiber Edition

• Fused Deposition Modeling (FDM) Process
• Maximum Build Volume:
  • Single Extrusion – 19 L x 19 W x 19.6 H cm (7.5 x 7.5 x 7.75 in)
  • Dual Extrusion – 15.2 L x 19 W x 19.6 H cm (6.0 x 7.5 x 7.75 in)
• Supported Materials: ABS, ASA, PLA, Tough, PVA, SR-30, Nylon, PETG, more to come

Fortus 450mc 3D Printer

• Fused Deposition Modeling (FDM) Process
• Build size - 406 x 355 x 406 mm (16 x 14 x 16 in)
• Various materials including high-performance thermoplastics

F170 3D Printer

• Fused Deposition Modeling (FDM) Process
• Build Tray Dimension - 254 x 254 x 254 mm (10 x 10 x 10 in)
• Materials - PLA, ABS-M30, ABS-CF10, ASA, TPU 92A, QSR Support Material

FormLabs Form 2 SLA 3D Printer

• Stereolithography (SLA)
• Build Volume - 145 x 145 x 175 mm (5.7 x 5.7 x 6.9 in)
• Resin based materials

FormLabs Form 3 SLA 3D Printer

• Stereolithography (SLA)
• Build Volume - 145 x 145 x 185 mm (5.7 x 5.7 x 7.3 in)
• Resin based materials

FormLabs Form Cure L

• Curing Volume – Cylinder 39.5 cm (15.6 in) in diameter and 32 cm (12.6 in) tall
• Turntable diameter – 39.5 cm (15.6 in)
• Maximum post-cure temperature – 80°C (176°F)

uPrint SE Plus

• Fused Deposition Modeling (FDM) Process
• Build Tray Dimensions – 8 x 8 x 6 inch (203 x 203 x 152 mm)
• Materials – ABSPlus P430, SR-30, SR-20, P400-SR, P400-R Support

Objet30 Prime

• PolyJet Print Technology
• Maximum Build Size (XYZ) – 294 x 192 x 148.6 mm (11.6 x 7.6 x 5.9 in.)
• Several Material Options Available

J850 Polyjet Stratasys

• PolyJet Print Technology
• Build Size - 490 x 390 x 200 mm (19.3 x 15.35 x 7.9 in)
• Several Material Options Available with Multi-material capabilities in a single print

VLS4.60 Laser System - VLS User Guide

• Work Area - 24 x 18 in (609.6 x 457.2 mm)
• Maximum Part - 29 x 23 x 9 in (737 x 584 x 229 mm)
• Maximum Part Weight - 40 lbs.

VLS6.60 Laser System - VLS User Guide

• Work Area - 32 x 18 in (812.8 x 457.2 mm)
• Maximum Part - 37 x 23 x 9 in (940 x 584 x 229 mm)
• Maximum Part Weight - 40 lbs.

Centroform EZFORM LV 1827 – Tabletop Vacuum Forming Machine

• Forming area: 18” x 27”
• Plastic Sheet Size: 21-1/4” x 30-1/4"
• Max. depth of draw 9 – 11 inches depending on mold Geometry

Go!Scan20 and Go!Scan50 Portable 3D Scanners

• Ideal for Reverse Engineering Applications
• Scanning Area:
  • Go!SCAN20 – 143 x 108 mm (5.6 x 4.3 in.)
  • Go!SCAN50 – 380 x 380 mm (15.0 x 15.0 in)
• Resolution:
  • Go!SCAN20 – 0.100 mm (0.0039 in.)
  • Go!SCAN50 – 0.500 mm (0.0197 in.)

Lathe Station #1

Southwestern Industries TRAK TRL1630SX

• Operate in CNC or Manual Mode
• ProtoTRAK SLX CNC
• 16” swing over bed, 30” between centers

Lathe Station #2

Clausing C1540FSJ

• Manual
• 7.5 HP Drive Motor and 15.25” swing over bed
• Distance between center 30”/40”/50”

Lathe Station #3

CC-D6000Ehs High Speed Benchtop CNC Lathe

• Benchtop CNC
• 2 HP High Speed Motor
• Indefinitely variable speed from 50 – 5000 rpm

Mill Station #1

Southwestern Industries ProtoTRAK K3SX

• 2-axis CNC, 3-axis DRO
• 3 HP spindle motor
• R8 spindle taper

Mill Station #2

HAAS Super Mini Mill 2

• 3 Axis CNC
• 15.0 HP with maximum speed of 10,000 RPM
• 20 Tool Capacity

Mill Station #3

HAAS OM2

• Haas-Built, 30,000 RPM ISO 20-Taper Spindle
• 5 HP Vector Drive
• 20-Pocket Electronic Tool Changer

Jet Horizontal Bandsaw

• Adjustable Material Stop
• Blade Speeds (SFPM) - 86, 132, 178, 260
• Cutting Ability - Ferrous/Non-Ferrous/Plastics

Jet Vertical Bandsaw

• 2 HP Motor and Blade Speeds (SFPM) – 100 – 3600
• 16” Max Height Capacity
• Work Table Size (L x W) – 27-1/4” x 20”

Jet 10” Industrial Bench Grinder

• 1-1/2 HP Motor
• Wheel Grits – 36, 60
• Wheel Diameter (Dia. X W) – 10” x 1”

Jet Belt Sander/Disc Sander

• 1.5 HP Motor
• 12" disc
• 6" x 48" belt

Kalamazoo - 42” Long x 1” Wide Vertical Belt Sanding Machine

• 1/3 HP
• Vertical Sanding Belt
• Belt – 42” L x 1” W

Denford 2600 Pro Router

• 3 Axis CNC Router
• Table Size – 700 x 430 mm (27.56 x 16.93 in)
• Travel (X/Y/Z) – 600 mm (23.62 in) x 400 mm (15.75 in) x 110 mm (4.33 in)

Vision Engineering Mantis Microscope

• Ergonomic, low fatigue visual inspection microscope
• Superior ergonomics for improved productivity
• Quick change turret for flexible magnification

Jet Drill Press (JDP-15B)

• 3/4 HP motor
• 16 Spindle Speeds with 3-1/8” spindle travel
• Table Size – 12-1/2” x 17”

Craftsman 10” Bench Drill Press

• 1/2" Chuck Size
• 1/2 HP Motor with 5 different speeds ranging from 680 – 3150 rpm
• 2-1/2” Spindle travel

Grizzly 1 HP Oscillating Spindle Sander

• Heavy-duty 1 HP motor
• Ten spindle sizes: 1/4”, 3/8”, 1/2”, 5/8”, 3/4”, 1”, 1-1/2”, 3”, 4”, tapered and threaded
• Spindle Speed – 1725 RPM

Wilton Vise

• 6” Jaw Width
• Hardened steel jaws and pipe jaws
• 360^o swivel and double lockdowns

Manual Arbor Press

• 3 Ton
• 1-3/4” Ram, 6” Throat Depth
• Ideal for staking, riveting, installing/removing bearings, and other press fit work

Carver Hydraulic Press

• 6” x 6” work area
• Manually Operated
• Analog Pressure Gauge

Delta Shopmaster Bandsaw

• 1/3 HP
• 9” Band Saw
• Designed for quality and precision cutting

Delta 20” Variable Speed Scroll Saw

• 1.3 Amps
• Speeds: 400 – 1750 SPM
• Designed for quality and precision cutting

Jet Belt Sander/Disc Sander

• 1.5 HP
• 12” disc
• 6” x 48” belt

DeWalt 12” Miter Saw

• 12” Blade diameter
• 15 Amp, 3800 RPM Motor
• 2” x 14” dimensional lumber cross cut capacity at 90^o, 2” x 10” at 45^o

Jet Horizontal Bandsaw

• Adjustable Material Stop
• Blade Speeds (SFPM) – 145, 200, 245
• Cutting Ability – Ferrous/Non-Ferrous/Plastics

Jet Vertical Bandsaw

• 2 HP Motor and Blade Speeds (SFPM) – 100 – 3600
• 16” Max Height Capacity
• Work Table Size (L x W) – 27-1/4” x 20”

Jet 10” Job Site Table Saw

• 10-inch blade
• Maximum depth of cut at 90 degrees: 3-1/8 in.; at 45 degrees: 2-1/2 in.
• Maximum Rip Right of Blade – 25 in.

Grizzly Cabinet Saw Model G0899

• 10-inch blade
• Maximum depth of cut at 90 degrees: 3-1/8 in.; 45 degrees: 2-1/8 in.
• Maximum ripping capacity – right of blade: 31-1/2 in.; left of blade: 11-3/8 in.

Router Table

• Bosch 1617EVA Router
• Kreg Precision Router Lift
• Router Work Table Size – 36” x 72”

Dewalt 13 in. Three Knife, Two Speed Thickness Planer

• 15-amp, 20,000 rpm motor
• Three knife cutter head
• Two-speed gear box

JWJ-8HH, 8” Helical Head Jointer

• 2 HP Motor
• 5500 RPM cutterhead speed
• 9” W X 72” L Table Surface, 36 knife inserts

Various Handheld Power Tools

• Circular Saws
• Angle Grinders
• Orbital Sanders
• Reciprocating Saws
• Jigsaws

Deluxe Portable Polishing Lathe Unit

• 350-Watt variable speed motor, 120 V, 60 Hz
• Up to 10,000 RPM
• Deluxe polishing outfit for professional results

Project Finishing Booth and Workbench

• Workbench with light
• Booth with exhaust and light
• Designated area for finishing various small projects

Maker Studio Collaboration Space Work Surfaces

• Solid Wooden Top Workbenches
• Composite Top Electrical benches
• Cutting Mats
• Bench Vises

Maker Studio Collaboration Space Toolbox

• Measuring Tools
• Screwdrivers, Wrenches, and Scissors
• Pliers and Files
• Clamps and Saws
• Hammers and Pry Bars
• Caulking Gun

Maker Studio Collaboration Space Storage Cabinets

• Basic Hand Tool Sets and Drills/Drivers
• Digital Multimeters, Function Generators, Power Supplies, Oscilloscopes
• Soldering Stations and Various Gauge Wire and Test Probes
• Other tools available upon request

Roland CAMM-1 GS-24 Desktop Vinyl Cutter

• Loadable Material Width - 2 to 27-½ in. (50 to 700 mm)
• Maximum Cutting Area - Width: 22.9 in (584 mm) Length: 984.25 in (25000 mm)
• Maximum Cutting Media Thickness – Up to 0.04 in (1 mm)

JUKI DNU-1541S Sewing Machine

• Max. sewing speed – 2,500 sti/min
• Max. stitch length – 9 mm (forward/backward)
• Heavy materials

JUKI DDL-5550N Sewing Machine

• Max. sewing speed – 5,500 sti/min
• Max. stitch length – 5 mm
• Medium-weight materials
